Implementing SSH tunnels in Elixir

By Simon Thörnqvist

Erlang OTP includes a SSH application I thought I would attempt to implement SSH tunneling in Elixir, similar to how we can define tunnels using openSSH.

With openSSH one can define a local tunnel using the following command:

ssh -nNT -L 8585: user@

This will forward any traffic on localhost:8585 to through . In other words localhost:8585 will connect to

The -nNT option tells SSH to run no command, redirect Null to stdin, and not allocate a TTY. So it’s not possible to run any commands through the tunnel. -L is for Local bind of the address, doing it in reverse is also possible by specifying the -R option and it even works for sockets too:

ssh -nNT -L 9000:/var/lib/mysql/mysql.sock user@

I’ve been writing this post alongside doing the implementation so it’s sort of a recollection of how it was implemented. The gists are for the most part correct and the full source can be found here.

We’ll define a module with a simple connect to create a connection to a ssh server:


Since we are calling the into erlang the host string (binary) needs to be encoded as a charlist.
Here we are using username / password for authentication as well as not allowing user interactions, any options requiring interactions will fail the connection attempt. There are a lot more options available for more fine grained control, but for us these options will suffice.

The ssh application needs to be started before we try to connect to the server:

# mix.exs
def application do
extra_applications: [:logger, :ssh]

And we can try it out:

iex(1)> {:ok, pid} = SSHt.connect(host: "", user: "ubuntu", password: "")

{:ok, #PID<0.181.0>}

It works! With this we are ready to start implementing the tunnels!

There are two kinds of tunnels which we are interested in

directtcp-ip allows us (the client) to connect to an ip:port using the ssh server and direct-streamlocal allows us to connect to unix domain socket.

directtcp-ip forwarding has been a part of erlang :sshapplication in the past but has since been removed, however we can implement it by using :ssh_connection_handler:open_channel/6 (source). This is the function used internally for creating channels ( :ssh_connection.session_channel/2/4 for instance).

For reference this is what it looks like

:ssh_connection:open_channel(ConnectionHandler, ChannelType, ChannelSpecificData, InitialWindowSize, MaxPacketSize, Timeout)
  • ConnectionHandler is the pid we receive from :ssh.connect
  • ChannelType is the type of message for us this will be either "dirrect-tcpip" or ""
  • ChannelSpecificData is the messag we’ll construct from the message format below
  • InitalWindowSize Initial TCP window size
  • MaxPacketSize Max allowed packet size

and the directtcp-ip message format:

string "direct-tcpip"
uint32 sender channel
uint32 initial window size
uint32 maximum packet size
string host to connect
uint32 port to connect
string originator IP address
uint32 originator port

We’ll define a direct_tcpip/3 function in the ssht.ex


On line 21 we create a message by translating from directtcp-ip message format to a binary, due to the excellent bit syntax it reads basically the same as the original message format from the specification.

Since the host fields can be of variable size, the length is prepended. Note that the SSH_MSG_CHANNEL_OPEN and sender channel fields are not part of our message. These will be set internally in :ssh_connection_handler.open_channel.

If you’re interested in reading more about binary pattern matching I think this article does a good job explaining it.

The type @direct_tcpip is defined as a module attribute, remember since we are calling an erlang application it needs to be represented as a charlist instead of a string. @max_window_size is set to the 32k as specified in rfc4253

6.1. Maximum Packet Length
All implementations MUST be able to process packets with an
 uncompressed payload length of 32768 bytes or less and a total packet
 size of 35000 bytes or less (including ‘packet_length’,
 ‘padding_length’, ‘payload’, ‘random padding’, and ‘mac’).

@ini_window_size is trickier since I don’t know the impact of setting a value which is too low (or too high). We’ll set it to 105kb since I’m pretty sure I’ve seen it set to 1024 * 1024 somewhere so we just go with that.

If our call to:ssh_connection_handler.open_channel/6 is successful we’ll receive a {:open, channel} . We’ll use the channel and the connection pid to call :ssh_connection.send/3 and send data to our forwarded ip. Let’s try it out by sending a raw HTTP message:

iex(1)>  {:ok, pid} = SSHt.connect(host: "", user: "ubuntu", password: "")
{:ok, #PID<0.166.0>}
iex(2)> data = "GET / HTTP/1.1\r\nHost: localhost:8080\r\nUser-Agent: ssht/0.0.1\r\nAccept: */*\r\n\r\n"
iex(3)> {:open, ch} = SSHt.direct_tcpip(pid, {"", 8080}, {"", 80})
{:open, 0}
iex(4)> :ssh_connection.send(pid, ch, data)
# handle the data returned on the connection with a receive block
iex(4)> receive do
...(4)> {:ssh_cm, _, {:data, ^ch, _, data}} -> IO.puts("#{data}")
...(4)> end

We can receive messages using a receive block or by creating the channel inside a process ( GenServer for instance) and receive it using handle_info/2 callback:

def handle_info({:ssh_cm, _, {:data, _ch, _, data}}, state) do
IO.puts("Received data #{length(data)}
{:noreply, state}

NOTE! I should say that it is required to have something actually responding on the forwarded ip otherwise it will fail. I have a VM setup with a private ip with nginx running on port 80.

So far we’ve achieved

  • Connecting to a ssh server
  • Creating a forwarded directtcp-ip channel which we can read & write to

What we don’t have is an actual TCP server to relay traffic from our host to the ssh server.

For this I’m using ranch, add ranch to the deps:

defp deps do
{:ranch, "~> 1.4"}

For this part we are going to do the following:

  • On demand TCP-servers
  • Relay traffic from a TCP client to forwarded ssh channel and back
  • Allow connecting using ip:port and a unix domain socket

The TCP servers need to be started on demand for this we’ll use DynamicSupervisor which is introduced in elixir 1.5 and deprecates the :simple_one_for_one strategy.

A cool feature unrelated to any of this is that DynamicSupervisorallows you to have different kinds of workers, since the only requirement is that you provided a valid child_spec when starting child processes.

We’ll define a lib/ssht/application.ex and put the following in it:

Here we set that we want to use the dynamic supervisor and give it a name. The strategy needs to be set to :one_for_one since it is the only supervison strategy supported by DynamicSupervisor. Notable is that since DynamicSupervisor implements the child_spec/1 function we can use the tuple shorthand. For more see the Supervisor docs.

Children can be started using:

DynamicSupervisor.start_child(SSHt.TunnelSupervisor, {MyGenServer, []})

First argument is the supervisor name, second is a child_spec. As long as the module implements a child_spec/1 it is safe to use the tuple shorthand. GenServer, Task, Supervisor all implements this so if you’re deriving your module from any of those you’re good to go. The second argument in the tuple are arguments to the child being started. In the example above we have no arguments so we specify an empty list.

We’ll define lib/ssht/tunnel.ex to use as our interface for creating TCP listeners.

start_link/2 accepts a ssh connection pid and a tuple which can either be {:tcpip, {local_port, {ip_addr, remote_port}} or {:local, socket_path} .

We use :ranch.child_spec in worker_spec/2 to create the specification for our TCP listener. worker_spec takes name, target from the options list and pattern matches on the target to determine the kind of listener we should use :tcpip for starting a port listener and :local for a domain socket listener.

We have yet to define the SSHt.Tunnel.TCPHandler which will be the process responsible for handling a TCP client connection. So let’s do that:

As you’ve probably already seen this looks a little bit different than usually. The reason for using :proc_lib.spawn_link is due to how GenServer.start_link works. start_link does not return until the init returns. Calling :ranch.accept_ack would cause a deadlock. We use :gen_server.enter_loop/3 to fallback to the normal GenServer execution loop after the initialization. (More here)

Time to receive TCP messages and send them onto the forwarded channel:

Whenever we get a tcp message we pattern match on {:tcp,_, data}and send data on to the ssh channel, when we receive a {:ssh_cm, _ {:data,_,_, data} message we send it on to the tcp socket. We also implement the terminate/2 callback to close the ssh channel when the client closes the socket, a EOF is received or for any unexpected behavior.

There’s a potential problem with this implementation however, since we need to differentiate between the connections there’s a channel created for every TCP connection. I’m not certain if it is a problem our not, initially I thought I would define a tunnel (channel) per TCP server, but as the channel is linked to the process creating it the TCP server would receive all ssh messages with no apparent way of telling messages apart. By doing it this way, we’re certain that the ssh messages received are destined to the correct TCP client.

I think it’s pretty cool that we are able to implement this in pure Elixir in about 200 lines. It’s just a testament to how incredible Erlang/OTP and Elixir really is!

The source in it’s entirety can be found here.

Some caveats:

  • The ssh pid should be monitored by each TCP server and trap it’s exit, since running a tunnel does not make much sense if the connection to the remote server is dead.
  • Defining a new channel for every connection might be sub-optimal
